Aluminum Fire Extinguisher Cabinets
Poseidon aluminum fire extinguisher cabinets are designed to provide lightweight, corrosion-resistant metal storage for portable fire extinguishers while keeping them visible, organized, and accessible during an emergency.
Standard cabinet sizes are available for 5 lb, 10 lb, and 20 lb / 2.3 kg, 4.5 kg, and 9.1 kg fire extinguishers. Custom configurations can be manufactured for surface-mounted, recessed, or semi-recessed installations, with options for door style, viewing panel, finish, color, hardware, and packaging.
- 5 lb
- 10 lb
- 20 lb
- Customized
Product Details
Lightweight Aluminum Cabinet for Fire Extinguisher Storage
Aluminum fire extinguisher cabinets are a practical choice for projects that require a metal cabinet with lower weight than steel and better corrosion resistance than standard painted carbon steel. The aluminum alloy body helps protect extinguishers from dust, moisture, routine contact, and minor impact while supporting easier handling and installation.
Compared with plastic cabinets, aluminum cabinets provide a more rigid structure and a cleaner architectural appearance. Compared with stainless steel cabinets, aluminum cabinets are lighter and can be a cost-effective option when weight, appearance, corrosion resistance, and project budget must be balanced.
Poseidon supplies standard aluminum fire extinguisher cabinets for 5 lb, 10 lb, and 20 lb extinguishers. As a manufacturer, we can also produce custom cabinet sizes, installation types, door styles, viewing panels, surface finishes, colors, locks, labels, logos, and packing methods based on distributor, contractor, and OEM requirements.
For recessed, semi-recessed, fire-rated, outdoor-rated, or code-sensitive installations, please confirm rough opening, wall projection, hardware, and local project requirements before production.
Size Options
| Model | Approx. Cabinet Dimensions |
| 5 lb / 2.3 kg Cabinet | 8.5″ W × 6.3″ D × 19.8″ H / 215.9 × 160.0 × 502.9 mm |
| 10 lb / 4.5 kg Cabinet | 9.5″ W × 6.3″ D × 25.8″ H / 241.3 × 160.0 × 655.3 mm |
| 20 lb / 9.1 kg Cabinet | 10.5″ W × 8.3″ D × 29.8″ H / 266.7 × 210.8 × 756.9 mm |
Technical Data
| Item | Description |
| Product Name | Aluminum Fire Extinguisher Cabinet |
| Application | Fire extinguisher storage / fire safety |
| Main Material | Aluminum alloy |
| Compatible Extinguishers | 5 lb, 10 lb, and 20 lb / 2.3 kg, 4.5 kg, and 9.1 kg portable fire extinguishers |
| Standard Sizes | Available for 5 lb, 10 lb, and 20 lb extinguishers |
| Installation Type | Surface-mounted standard; recessed and semi-recessed available by custom order |
| Door Options | Solid door, full-window door, vertical duo door available by custom order |
| Viewing Panel Options | Clear acrylic glazing; tempered glass available upon request |
| Finish Options | Natural aluminum, clear anodized, powder-coated, or painted finish |
| Color Options | Aluminum finish, red, white, or custom colors |
| Hardware Options | Handle, lock, hinge, latch, and mounting hardware available by request |
| Customization | Size, installation type, door style, finish, color, hardware, logo, label, and packaging |
| Hazardous Chemical | No |
| Packaging | 1 piece per carton or custom packing |
| OEM / Project Supply | Available |
Note: Dimensions are approximate cabinet dimensions. Final fitment should be confirmed based on extinguisher height, cylinder diameter, valve, hose, nozzle, bracket, and mounting method. For recessed or semi-recessed models, rough opening and wall projection should be confirmed before production.
Product Features
- Aluminum alloy body: Lightweight, corrosion resistant, and recyclable.
- Metal cabinet structure: Helps protect extinguishers from dust, moisture, and routine contact.
- Reduced weight: Easier to handle and install than many steel cabinet designs.
- Standard size range: Available for 5 lb, 10 lb, and 20 lb / 2.3 kg, 4.5 kg, and 9.1 kg extinguishers.
- Mounting options: Surface-mounted standard; recessed and semi-recessed designs by custom order.
- Door options: Solid door, full-window door, and vertical duo door available.
- Viewing panel options: Clear acrylic glazing or tempered glass upon request.
- Finish options: Natural aluminum, clear anodized, powder-coated, or painted finish.
- Custom colors: Aluminum finish, red, white, or project-specific colors.
- Hardware options: Lock, handle, hinge, latch, and label options available.
- OEM support: Size, structure, logo, packaging, and product configuration can be customized.
Recommended Uses
Poseidon aluminum fire extinguisher cabinets are suitable for projects that require lightweight metal construction, corrosion resistance, and a clean professional appearance.
Typical applications include:
- Commercial buildings: Offices, hotels, retail spaces, shopping centers, and public areas.
- Architectural interiors: Projects requiring a cleaner metal finish than standard painted steel.
- Schools and institutions: Hallways, utility areas, equipment rooms, and facility safety points.
- Hospitals and public facilities: Locations where clean appearance and corrosion resistance are important.
- Light industrial facilities: Workshops, maintenance rooms, warehouses, and support areas.
- Moisture-prone indoor areas: Areas where aluminum is preferred over standard carbon steel.
- Facility retrofit projects: Installations where lighter cabinet weight helps simplify handling.
- Distributor product lines: Standard or custom aluminum cabinets for fire safety suppliers.
- OEM and project orders: Custom size, finish, door style, hardware, logo, and packaging requirements.
Need Aluminum Fire Extinguisher Cabinets for Your Project?
Send us your required extinguisher size, cabinet dimensions, installation type, door style, viewing panel, finish, color, hardware, quantity, and customization details. Poseidon can manufacture standard and custom aluminum fire extinguisher cabinets for 5–20 lb / 2.3–9.1 kg portable fire extinguishers.
Our team can help confirm fitment, cabinet dimensions, rough opening requirements, wall projection, door configuration, viewing panel, lock option, finish, packaging, MOQ, lead time, and bulk pricing before production.
Submit your requirements to get a quotation and product details for your order.
