Handline Fire Hose Nozzle
The Poseidon Handline Fire Hose Nozzle is a selectable gallonage combination nozzle for structural fire attack, industrial fire brigades, training, exposure protection, and foam-supported operations. It supports adjustable flow settings from 15–950 LPM (3.96–250.96 GPM), straight stream and fog patterns, and inlet sizes from 1 in to 2.5 in.
Built with a hard-anodized aluminum body, rubber bumper, and multiple coupling options including Storz, NH, Instantaneous, BSP, GOST, and Machino, the nozzle is designed for dependable handline performance and OEM supply programs.
| Specification | Available Options / Data |
| Product Name | Handline Fire Hose Nozzle |
| Nozzle Type | Selectable gallonage combination handline nozzle |
| Model Example | PS2045-K |
| Flow Control Method | Flow-setting knob |
| Shutoff / Valve Type | Ball valve for selectable-gallonage models; slide valve for high-pressure jet spray variant |
| Stream Pattern | Straight stream and adjustable fog pattern |
| Body Material | Hard-anodized aluminum |
| Handle Material | Injection-molded nylon; hard-anodized aluminum trigger on high-pressure model |
| Nozzle Bumper | Rubber protective bumper |
| Valve Material | Aluminum, ABS, stainless steel, or model-dependent components |
| Fog Pattern Method | Molded teeth; ABS or stainless steel teeth available |
| Available Inlet Sizes | 1 in, 1.5 in, 2 in, 2.5 in |
| Recommended Inlet Sizes | 1 in for compact low-flow models; 1.5 in for mid-range handline models; 2.5 in for high-flow models |
| Available Connections | Storz, NH, Instantaneous, BSP, GOST, Machino, and custom coupling options |
| Standard Flow Ranges | 15–60 LPM / 3.96–15.85 GPM; 50–230 LPM / 13–61 GPM; 115–475 LPM / 30.38–125.48 GPM; 360–950 LPM / 95.1–250.96 GPM |
| High-Pressure Jet Spray Flow | 20–150 LPM / 5.28–39.63 GPM |
| Example Flow Setting | 475 LPM / 125.48 GPM |
| Working Pressure | 6–25 bar / 87–363 psi for standard models; 6–40 bar / 87–580 psi for high-pressure model |
| Typical Operating Pressure | 7 bar / 100 psi |
| Maximum Pressure | 25 bar / 360 psi for standard selectable-gallonage model |
| Max Fog Angle | 110° standard; up to 120° on selected variants |
| Max Reach | 25–55 m / 82–180 ft depending on model, flow setting, pressure, and stream pattern |
| Product Weight | Approx. 1.6–2.8 kg / 3.5–6.2 lb depending on model and coupling |
| Example Package Size | 35 × 25 × 30 cm / 13.8 × 9.8 × 11.8 in; 36 × 30 × 16 cm / 14.2 × 11.8 × 6.3 in; 77 × 39 × 34 cm / 30.3 × 15.4 × 13.4 in |
| Bulk Carton Example | 76 × 39 × 109 cm / 29.9 × 15.4 × 42.9 in; 56.5 kg / 124.6 lb; 15 pcs/carton |
| Color Options | Black/red standard; custom colors available for OEM orders |
| Reference Standard | Designed with reference to NFPA 1964 fire hose nozzle performance concepts; no third-party certification implied |
| OEM Options | Flow range, inlet size, coupling type, handle color, bumper color, teeth material, logo marking, packaging |
The Poseidon Handline Fire Hose Nozzle is engineered for controlled water delivery in active firefighting environments. Its selectable gallonage design allows the operator to choose the rated discharge through a flow-setting knob, supporting different tactical needs such as interior attack, exterior cooling, exposure protection, mop-up, and training operations.
The combination nozzle design supports both straight stream and fog stream patterns. Straight stream operation provides reach and penetration for direct fire attack or exposure cooling, while fog patterns support heat absorption, hydraulic ventilation support, and personnel protection in close-range operations. Standard models provide a maximum fog angle of 110°, while selected variants support up to 120°.
The nozzle body is manufactured from hard-anodized aluminum to provide corrosion resistance, impact durability, and reduced operating weight compared with heavier brass components. The injection-molded nylon handle improves grip and thermal comfort during extended hose handling. A rubber bumper protects the nozzle head from impact damage during deployment, dragging, transport, and repeated fireground use.
Standard selectable-gallonage models use a ball valve shutoff for smooth open/close control during hose advancement and nozzle handling. The flow-setting knob selects the rated discharge, while the shutoff valve controls water delivery. A high-pressure jet spray variant is available with a slide valve configuration for specialized operating requirements.
Depending on the selected model, flow ranges include 15–60 LPM (3.96–15.85 GPM), 50–230 LPM (13–61 GPM), 115–475 LPM (30.38–125.48 GPM), and 360–950 LPM (95.1–250.96 GPM). Standard models operate within 6–25 bar (87–363 psi), with typical operation at 7 bar (100 psi). High-pressure jet spray models may operate within 6–40 bar (87–580 psi).
For foam-supported operations, the nozzle can support Class A and selected Class B foam applications when used with compatible foam agents, proportioning equipment, and correct operating pressure. Foam performance depends on the foam concentrate, proportioner, discharge rate, nozzle pattern, and system configuration.
Poseidon offers OEM and bulk supply options for distributors, fire departments, industrial fire brigades, and firefighting equipment brands. Customizable options include inlet size, coupling type, flow range, color, handle style, bumper material, teeth material, logo marking, and packaging.
- Selectable flow range: 15–950 LPM (3.96–250.96 GPM)
- Straight stream and adjustable fog pattern control
- 110°–120° maximum fog angle, depending on model
- Hard-anodized aluminum body for corrosion and impact resistance
- Ball valve shutoff with separate flow-setting knob
- Rubber bumper for nozzle head protection
- Inlet sizes: 1 in, 1.5 in, 2 in, 2.5 in
- Couplings: Storz, NH, Instantaneous, BSP, GOST, Machino
- Foam-compatible when used with proper foam agent and proportioner
- OEM options for flow range, coupling, color, bumper, teeth, marking, and packaging
- Structural handline fire attack
- Industrial fire brigade response
- Exposure protection and exterior cooling
- Class A and selected Class B foam operations
- Wildland and WUI mop-up support
- Fire academy and hose handling training
- Hangar and high-risk facility support
- Confined-area fire response
